FULL-AUTOMATIC MICROVICKER HARDNESS TESTER FM-ARS 9000
Full-Automatic MicroVicker Hardness Tester FM-ARS 9000 is a more innovated Vickers hardness testing system
Features of Full-Automatic MicroVicker Hardness Tester
FM-ARS 9000 is a Full-Automatic MicroVicker Hardness Testing Machine manufactured by Future-Tech – Made in Japan
Sampleʼs Tilted Surface Tracing Function
- Easy setting of tilt angle enables to control Z-axis along the sampleʼs tilted surface.
- This function enhances “Load applying accuracy”, shortens “Auto-focus time” and protects a sample and lens/indenter from a collision.
Measured Image Saving Function
- You can check the images of all the measured indents.
- By re-measuring the indent’s image, you can modify data easily.
Various Measurement Patterns
A series of measurement operations: Continuous Indentation – Focusing – Reading – Data Record: Just by selecting a measurement pattern, all testing will be full-automatic with high speed.
- Most Advanced System with High-speed Sample Profile Memory Function.
- High-speed, High-accuracy, High-repeatability, Easy-operation, Improved Read Power.
- More Reliable for Large quantities of testing without human error.
Data Processing Software
Capability of Reading unclear indents on un-mirror surface has been improved by more advanced Data Processing Software.
Various Data Output Format and Statistical Processing
- Case Depth of indicated HV Hardness can be displayed instantaneously on the Chart after continuous Measurements on Carbonized Layer.
- Various Data Output available – Measurement Data, Hardness Distribution Chart, Case Depth, Max. Value, Min. Value, Mean Value, Dispersion, Standard Deviation, Coefficient of Variation, OK-NG Criteria, Conversion Data, etc.
- Display and Output of Color Profile Picture linked with Hardness Values – Standard Function.
Specifications of the Full-Automatic MicroVicker Hardness Tester
STANDARD SYSTEM COMPONENTS
Analog Microhardness Tester Model: FM-110S (OPTION: FM-310S, FM-810S available)
Automatic X-Y Stage & Motor Drive Unit
CCD Camera
Complete set of PC: 23” TFT Wide LC Monitor, Mouse, Keyboard, and Joy-Stick with Controller
Standard Software for System ARS 9000
HARDNESS TESTER
Model
Model FM-110S：Stage Elevation Motor Built-in
Type
Analog Type：Controllable Loading Operation by External PC
Test Load
Test load type (A ~ D) can be selected. (FM-110S / FM-310S series)
Test load type (A ~ E) can be selected. (FM – 810S series)
Setting is different between models.
For details, contact the sales department of our company
Loading Mechanism
Automatic Load / Hold / Release Method
Focus Operation
Automatic / Manual Operation available
* Focusing Steps adjustable
Auto-Stage Elevation
Automatic: by Built-in Stepping Motor / Manual: by Standard Handle & Joy-Stick Operation
* Safety Devices equipped for Overrun of Elevation
Precision Vise
Standard: Max. Opening: 50mm
Rotation Turret
Automatic / Manual changeable
Load Applying Speed
60μm / sec
Dwell Time
5 – 40 sec
Object Lens
x10 / x50 (Optical Parts for 3rd Lens Built-in)
AUTOMATIC MEASUREMENT SCALE
Vickers Hardness (HV) / Knoop Hardness (HK)
AUTOMATIC X-Y STAGE
Driving Motor
Stepping Motor
Driver Control
By icon : 2 Steps Speed available in X Y Z axis
By Joy-Stick : Flexible Speed Changing in X Y Z axis
Dimension
110 x 110 mm
Max. Movement
50 x 50 mm
Min. Movement
1 μm
Moving Speed
1 – 25 mm / sec adjustable
Movement Program Pattern
Straight Line (Vertical & Horizontal) / Zigzag / Circle / Arc / Line Set for any Angle (8 Lines and Max. 998 indents on 1 Line/Total 49950 indents are measurable.) / Random
AUTOMATIC READING
Pattern Setting
Start Position Setting for Straight Line and Position Setting for Random/Teaching Mode shall be performed by Mouse-Click.
Measurement Repeatability
± 0.8 % on Test Block 700 HV / 500 gf
Auto-Focus Time
Shortest 3 sec
Auto Reading Time
Approx. 0.2 sec / 1 dendent
Measurable Min. Indent
10 μm
Min. Measurement Unit
0.1 μm
